NON-DIRECTIONAL
| SIZE (inch) | P.R. | R.W. (inch) | O.D.(mm) | S.W. (mm) | N.S.D. (mm) | MAX LOAD single (kg) | MAX LOAD single (lbs) | MAX LOAD double (kg) | MAX LOAD double (lbs) | INFLATION (bar) | INFLATION (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 165R13C 94/92P | 8 | 4.5 | 602 | 160 | 8.2 | 670 | 1475 | 640 | 1410 | 4.5 | 65 |
| 175R13C 97/95P | 8 | 5.0 | 613 | 178 | 8.2 | 730 | 1610 | 690 | 1520 | 4.5 | 65 |
| 185R14C 102/100P | 8 | 5.5 | 653 | 184 | 9.6 | 850 | 1875 | 800 | 1765 | 4.5 | 65 |
| 195R14C 106/104P | 8 | 5.5 | 668 | 193 | 9.6 | 950 | 2095 | 900 | 1985 | 4.5 | 65 |
